CE FCC Compliant 100w Power Supply Input 100-240V Output 5v 20a Ac Dc Power Adapter

FOB Reference Price:Get Latest Price
$24.50 - $26.50 / Pieces | 100 Piece/Pieces (Min. Order)
Lead Time:
Quantity(Pieces) 1 - 100 >100
Est. Time(days) 10 Negotiable
Samples - $33.15 /Pieces, 1 Pieces (Min. Order): Buy Samples
Loading...
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
Pengchu
Model Number:
PC-050200
Output Type:
DC
Connection:
Desktop
Input:
AC 100-240v 50-60hz
Output power:
100w
Output voltage:
5v
Output current:
20a
Efficiency:
81% Min
Aging test:
100% full load test
Material:
100% PC
PFC:
>0.99
Certificate:
CE FCC RoHS
Warranty:
2 Years
Supply Ability
Supply Ability:
150000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
brown box with bubble bag inside
Port
Shenzhen
Lead Time :
Quantity(Pieces) 1 - 100 >100
Est. Time(days) 10 To be negotiated
Video Description

CE FCC Compliant 100w Power Supply Input 100-240V Output 5v 20a Ac Dc Power Adapter

Product Description



product features:

1. Appearance design ---- Without fan but natural cooling and low noise

2. With LED indicator light

3.With high PFC function

4. With PC material , it’s  high temperature resistance, fireproof.

5.With 4 protections : Short Circuit Protection ; Over Voltage Protection ;Over
   Current Protection ; Over temperature protection

6.Real power,full load aging testing,100% loading testing.



Part. No. PC-050200
Product size200*100*45 mm
AC Input100~240V AC 50/60Hz  Max:90~264V AC 47/63Hz
DC Voltage5V
Rate Current20A
Current Range0~20A
Rate Power100W
Material100% PC
CertificationApproved CE RoHS FCC C-TICK certification
Rippe & Noise<120MVP-P
Voltage Tolerance±5%
Line Regulation±1%
Load Regulation±5%
Efficiency>81%
PFCMore than 0.99
Short Circuit Protection

Shall be protected when any output operation in circuit short condition, and shall be auto restart when the fault condition is removed.

Over Current Protection130%~150%
Over Voltage Protection115%~135%
Operating Temperature-10℃~50℃(±10℃)
Relative Humidity20%~90% RH
Storage Temperature-40℃~80℃(±10℃)
DC Connector4pin, 6pin or Customized available
DC Cable0.6m, 0.8m, 1m (Customized available)
AC CableUSA/UK/EU/AU/India Plugs(Customized available)
Product details
