Hot Selling Ac Power Supply 12v 40a PSU 480w Power Supply For Led Lcd CCTV Camera

FOB Reference Price:Get Latest Price
US $68.5-75.5 / Pieces | 100 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
Penghchu
Model Number:
PC-120400
Output Power:
401 - 500W
Output Type:
Single, Single
Input Voltage:
100v 240vac
Output Voltage:
12v
Output Frequency:
50/60Hz
Output Current:
40a
Input:
AC 100-240v 50-60hz
Output:
12v 40a 480w
Color:
Black
Protection:
OVP OCP OTP SCP
Certification:
CE FCC ROHS
Warranty:
2 Years
Type:
Desk
Usage:
LED Light
Aging test:
100% aging test
Supply Ability
Supply Ability:
150000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Brown Paper Box
Port
Shenzhen

Hot Selling Ac Power Supply 12v 40a Psu 480w Power Supply For Led Lcd Cctv Camera



Product Description

Features:

(1)High efficiency, High reliability, Long life time

(2)Efficiency: 88% min

(3)Approved CE RHOS FCC  certification

(4)Warranty: 2 year

(5)Protection: Over current protection, Over voltage protection, Short  circuit  protection; Over temperature protection.

(6) Real power, high reliablity, long life
     IEC320-C14, IEC320-C6 AC inlet optional
     OEM/ODM welcome (special voltage & dc connector & logo & package).

(7)Suit for: LED, LCD, CCTV camera, Motor,etc

Part. No. PC-120400
AC Input100~240V AC 50/60Hz  Max:90~264V AC 47/63Hz
DC Voltage 12V
Rate Current 40A
Current Range 0~40A
Rate Power 480W
Rippe & Noise <120mV
Voltage Tolerance±5%
Line Regulation±1%
Load Regulation±5%
Efficiency>88%
Short Circuit Protection

Shall be protected when any output operation in circuit short condition, and shall be auto restart when the fault condition is removed.

Over Current Protection130%~150%
Over Voltage Protection115%~135%
Operating Temperature-10℃~50℃(±10℃)
Relative Humidity20%~90% RH
Storage Temperature-40℃~80℃(±10℃)
Dielectric Withstand Voltage(HI-POT)100% of line products of this adapter shall be applied 3000V AC or 4242V DC for a minimum of 1 minute between AC input terminals and output terminals
Cut-off current is specified as 10mA
Insulation-resistance100M ohms
DC Connector4pin or 6pin(Customized available)
DC Cable1.2M, 1.5M, 1.8M(Customized available)
AC CableUSA/UK/EU/AU/India Plugs(Customized available)
Application



AC Plug& DC
